Our BM series aluminum profile extrusion press machines represent the pinnacle of industrial extrusion technology, designed to meet the demanding requirements of modern aluminum profile manufacturing. With a comprehensive range from 600T to 2000+ ton capacity, these robust machines deliver exceptional performance, precision, and reliability for aluminum extrusion operations of all scales.
| Parameter | Minimum | Maximum |
|---|---|---|
| Diameter of main cylinder plunger | 580 mm | 950 mm |
| Diameter of side cylinder plunger | 140 mm*2 | 220 mm*160 mm |
| Diameter of container plunger | 160 mm*4 | 180 mm*4 |
| Diameter of shear plunger | 140 mm | 200 mm |
| Total extrusion force | 648.5 ton | 2039 ton |
| Main cylinder extrusion | 580.9 ton | 1842 ton |
| Side cylinder extrusion | 67.6 ton | 197 ton |
| Container lock-up | 36 ton | 80 ton |
| Shear | 24 ton | 70 ton |
| Operation | Minimum Speed | Maximum Speed |
|---|---|---|
| Main cylinder fast forwarding speed | 315 mm/sec | 125 mm/sec |
| Main cylinder fast draw-back speed | 200 mm/sec | 275 mm/sec |
| Extrusion speed | 0-12 mm/sec | 0-17 mm/sec |
| Container lock-up | 200 mm/sec | 300 mm/sec |
| Container open | 180 mm/sec | 169 mm/sec |
| Shear up | 350 mm/sec | 350 mm/sec |
| Shear down | 300 mm/sec | 600 mm/sec |
Window and door frame profiles, curtain wall systems, architectural components
Heat sink profiles, automotive trim, solar panel framing, machinery frames
Railway components, automotive structural parts, marine applications
Furniture frames, consumer electronics, household appliances
We provide comprehensive after-sales support including field installation, commissioning and training services. Each machine is backed by our technical support team to ensure optimal performance and productivity.
Our streamlined process ensures efficient project delivery from initial consultation to final implementation.
Frequently Asked Questions - Find answers to common questions about our products and services
A. Leave us massage with your purchase requirements and we will reply you ASAP. And you may contact us directly by Trade Manager or Telephone.
A. Yes, we provide smart solutions for our customer, in order to increase efficiency.
A. Yes, free training in our factory is available.
A. Send me details about what you need, you will get the best price for the best machine. The price is competitive over the world.
A. One year warranty for normal use and we supply maintenance for free.
A. We accept payment methods such as L/C, T/T, DP, DA and so on.
A. Yes, our company has a team of professional engineers from Taiwan.
A. Our factory adopts mature Italy sub technology.
